EP-510H Separable Hydraulic Crimping Tools Technical parameters





FUNCTION:
1、It is specially designed for inside and outside power transmission and distribution project,various kinds of connecting terminals,overhead and underground cabling.
2、Criming high voltage cable sleeve,wire grips,un-insulated terminals,hexagon terminals Crimped part tight and uneasy to break out in good conductivity.
3、Dies could be ordered and available in any sizes.
4、The oil pipe coupler fitted with PT3/8" thread.
EP-510H Separable Hydraulic Crimping Tools
Technical parameters：
Output(T)13
Ram Stroke(mm)38
Contact Range(mm²)50-400
Size(mm)380×120×75
Weight(kg)4
Standard Mould50、70、95、120、150、185、240、300、400mm²
Http://www.china-hydraulic-tools.com
Http://www.sitoot.com
E-mail:sitoot@sitoot.com
